HDMI Splitter with Audio Extractor, HDMI Splitter 1 in 2 Out 4k 60 with 3.5mm Stereo Audio and Multi-Resolution Output, Supports Downscale, HDR, 18 Gbps, HDCP 2.2, for Xbox PS5 Soundbar UHD TV

Price: $49.99
(as of May 31, 2025 14:08:18 UTC – Details)

Product Description

The MSQ-720P 4K HDMI 2.0a 1×2 Splitter with Audio Extractor is the most cost-effective HDMI splitter solution, allowing the transmission of high-definition video and high-quality audio to 2 different locations without any quality loss. Additionally, MSQ-720P supports HDR and true 4K2K video. Without sacrificing any active audio channels from the audio bitstream, this device supports the separation of high-quality digital S/PDIF (Toslink) audio from the incoming HDMI signal.

The compatibility among various HDMI sources and receivers could also be ensured with built-in USB firmware update mechanism. The MSQ-720P is ideal for high quality HDMI broadcasting, digital signage, and educational applications since it supports the highest HDR/4K2K@60 4:4:4 8bits and high-definition audio!

*Please note that this product CANNOT be powered by a PC.*

FEATURES/SPECIFICATION

HDMI 2.0a /HDCP 2.2 and 1.4 CompliantSupports 4K2K@60 4:4:4 8bits, HDR(4K2K@60 4:2:0 10bits)Controllable 4K to 1080P Downscale Using Dip SwitchWide Frequency Range: 25MHz ~ 600MHzVideo Bandwidth: 18GbpsHDMI Audio Format: PCM2/5.1/7.1, Dolby 5.1/7.1, DTS 5.1/7.1Optical Audio Format: PCM2, Dolby 5.1, DTS 5.1Supports Audio Extraction via ToslinkSupports xvYCC, x.v.Color and Deep ColorMicro-USB Firmware Update for Expanding Compatibility

Package Content 1x MSQ-720P 1x DC 5V 1x Micro-USB Cable 1x User Manual

Downscale 4K to 1080P Automatically

Detect the HDMI incoming signal and downscale it automatically to be compatible with 1080p displays for the output 1 and 2.

Also, the specially designed feature the DIP switch lets you select between default EDID, copy EDID, or learning EDID.

Audio Extraction (Digital Toslink Or Analog Stereo)

Extract high-quality audio

– Stereo 3.5mm phone jack supports 2 channel PCM

– Toslink S/PDIF jack supports: LPCM 2ch/5.1ch, Dolby 5.1, Dolby 7.1, DTS 5.1, DTS 7.1, DTS-HD Master Audio and Dolby TrueHD.

Same Screen Sharing

Effortlessly duplicate a single HDMI signal to two locations simultaneously without any loss in quality.

FAQ

Question #1: Does it support 3D?

A: Yes.

Question #2: Support ARC?

A: No, it does not support ARC.

⚡【HDMI 1 In 2 Out Splitter】Effortlessly duplicate one HDMI signal to two displays simultaneously without any quality loss. Supports HDMI 2.0, HDCP 2.2/1.4, 3D and HDR, resolution up to 4K2K 60Hz 4:4:4 8bits. Also, the downscale function detects the HDMI source signal and downscales it automatically to be compatible with 1080p monitors for output 1 and 2.
⚡【Splitter with Audio Extraction】Extract embedded audio from HDMI inputs and output to high-quality digital Toslink (S/PDIF) or analog stereo 3.5mm phone jack. Enjoy optimal audio-video synchronization experience with just one device. *Please note that this device does not support ARC.*
⚡【Multi-Resolution Output】The specially designed feature allows you to easily downscale your 4K signal input to perfectly fit a 1080p display. Additionally, the DIP switch lets you select between default EDID, copy EDID, or learning EDID for effortless configuration, ensuring broad HDMI video compatibility.
⚡【Wide Compatibility】Flexible and ideal HDMI device with wide compatibility, perfect for live streaming, home theater, meetings, and entertainment, supporting various HDMI source devices such as TV Box, Blu-ray/DVD/HD players, Apple TV, Roku, gaming consoles (PS3/PS4/PS5, Xbox/Xbox Series X/S, Nintendo Switch), HD cameras, PC/laptop, HD DVRs and others.
⚡【Superior Quality and Customer Service】Made in Taiwan(TAA Compliant), all MAXSQUARE products come with ESD protection and are CE/FCC/RoHS certified. We provide lifetime technical support and a 12-month warranty for each item you purchase. For further technical support, please refer to the user manual.
